When Should You Replace SF6 Switchgear with SF6-Free Alternatives?

SF6 switchgear has been widely used in medium voltage and high voltage electrical networks for decades. Its strong insulating and arc-quenching performance made it a preferred solution for substations, utilities, industrial facilities, commercial buildings, renewable energy projects, and critical infrastructure.

However, many asset owners are now asking the same question: when is the right time to replace SF6 switchgear with SF6-free switchgear?

The answer is not always “immediately.” If existing SF6 equipment is still safe, compliant, and operating reliably, replacement may be planned as part of a future upgrade. But if the switchgear is ageing, leaking, difficult to maintain, or no longer aligned with sustainability and compliance requirements, it may be time to evaluate SF6-free alternatives.

SF6 is a powerful greenhouse gas. The U.S. EPA notes that SF6 is 23,500 times more effective at trapping infrared radiation than CO₂ over a 100-year period and remains in the atmosphere for more than 1,000 years.

Why Companies Are Moving Away from SF6 Switchgear

The shift toward SF6-free switchgear is driven by three major factors: environmental responsibility, regulatory pressure, and operational simplicity.

Traditional SF6 switchgear requires gas monitoring, gas handling procedures, leakage prevention, trained personnel, and proper gas recovery at end of life.

These requirements can increase lifecycle complexity, especially for organisations operating multiple switchgear assets across different sites.

In Europe, Regulation (EU) 2024/573 has introduced staged restrictions for new switchgear using fluorinated gases. The European Commission’s switchgear FAQ states that new medium-voltage switchgear up to 24 kV must use no F-gas from 1 January 2026, while switchgear above 24 kV up to 52 kV must use no F-gas from 1 January 2030, subject to specific derogations.

Even for markets outside Europe, these changes influence global procurement, manufacturer roadmaps, corporate sustainability targets, and long-term asset planning.

Replace SF6 Switchgear When the Equipment Is Near End of Life

One of the clearest times to replace SF6 switchgear with SF6-free switchgear is when the existing equipment is approaching the end of its service life.

Ageing switchgear may still operate, but older equipment often comes with higher risks. Spare parts may become harder to source, maintenance procedures may take longer, and outage planning may become more complicated.

If the equipment is already due for major refurbishment, it is usually more strategic to evaluate a full SF6-free replacement instead of extending the life of older SF6 assets.

Replacement should be considered when:

• The switchgear has been operating for decades

• Spare parts are limited or discontinued

• Maintenance costs are increasing

• The equipment requires frequent inspection or intervention

• The site is already planning an electrical upgrade

• Reliability expectations have changed

For many facilities, the best replacement window is not after a failure. It is during a planned shutdown, capacity upgrade, substation expansion, or lifecycle renewal program.

Replace SF6 Switchgear When Gas Leakage Becomes a Concern

SF6 leakage is one of the strongest reasons to assess replacement.

A small leak may appear manageable at first, but repeated gas top-ups, pressure alarms, leak detection work, and repair activities can increase both cost and operational risk. Because SF6 has a very high global warming potential, even small emissions can have a significant environmental impact.

The European Commission FAQ states that operators of switchgear containing relevant F-gases must prevent emissions where feasible, repair detected leakage without delay, perform required leakage checks, ensure recovery of F-gases, and use certified technicians for installation, maintenance, repair, and decommissioning.

If an asset requires recurring leak repairs, the business case for replacement becomes stronger. At that stage, the question is no longer only technical. It becomes a lifecycle cost and environmental risk decision.

Replace SF6 Switchgear During Major Site Upgrades

SF6-free switchgear should be strongly considered when a facility is already upgrading its electrical infrastructure.

This may include:

• Adding new feeders

• Expanding production capacity

• Connecting renewable energy systems

• Installing battery energy storage systems

• Upgrading a commercial building

• Modernising a utility substation

• Improving power reliability for a data centre

• Replacing outdated medium voltage equipment

When a site is already investing in new electrical infrastructure, installing another generation of SF6-based equipment may create long-term risk. Switchgear is a long-life asset, often expected to operate for decades. A decision made today can affect compliance, maintenance, ESG reporting, and replacement cost far into the future.

For new projects and major upgrades, SF6-free technology is often the more future-ready option.

Replace SF6 Switchgear When Maintenance Is Becoming Too Complex

SF6 switchgear is reliable when properly maintained, but the gas itself creates additional maintenance requirements.

Operators may need to manage gas density checks, leakage inspections, gas recovery, documentation, specialist handling, and certified service personnel. The German Environment Agency notes that switchgear containing fluorinated greenhouse gases can be subject to leakage checks, record keeping, personnel certification, and recovery obligations depending on design and gas quantity.

SF6-free switchgear can reduce this operational burden. Modern SF6-free medium voltage systems often use clean air or dry air for insulation and vacuum interrupters for switching. Leistung Energie’s Airing SF6-free medium voltage switchgear, for example, uses dry air with no SF6 and is positioned as a maintenance-free solution with recyclable materials.

This makes SF6-free switchgear especially attractive for facilities that want to simplify long-term maintenance and reduce dependence on specialised SF6 gas handling.

Replace SF6 Switchgear When Sustainability Targets Matter

Many organisations now have decarbonisation targets, ESG reporting requirements, green building goals, or internal sustainability policies. In these cases, SF6 switchgear can become a visible environmental liability.

This is especially relevant for:

• Renewable energy projects

• Data centres

• Commercial buildings

• Hospitals

• Universities

• Airports

• Rail and transport infrastructure

• Utilities with net-zero commitments

• Industrial companies reporting Scope 1 emissions

Although switchgear is only one part of an electrical system, replacing SF6 equipment can support a broader sustainability strategy. SF6-free alternatives help reduce the risk of future gas emissions and remove the need to manage a high-GWP insulating gas throughout the equipment lifecycle.

Replace SF6 Switchgear When Future Regulation Could Affect Procurement

Even if local regulations do not yet require immediate replacement, regulatory momentum is moving toward lower-emission switchgear technologies.

This matters because switchgear procurement is rarely a short-term decision. Specification, tendering, delivery, installation, commissioning, and approval can take months or even years, especially for infrastructure and utility projects.

In the EU, the restriction dates are based on when switchgear is “put into operation,” not merely when it is ordered or delivered. The European Commission FAQ defines putting into operation as the handover of equipment to the operator after required tests and inspections.

This is important for project planning. If a project is delayed, equipment that seemed acceptable at the procurement stage may face compliance challenges by the commissioning stage. For buyers, specifying SF6-free switchgear from the beginning can reduce future regulatory uncertainty.

Replace SF6 Switchgear When Total Cost of Ownership Supports It

The initial cost of SF6-free switchgear may not always be the lowest option. However, replacement decisions should consider total cost of ownership, not only purchase price.

A proper evaluation should include:

Cost Factor	Why It Matters
Equipment cost	Initial capital expenditure for new switchgear
Installation cost	Civil works, electrical room changes, downtime, and commissioning
Maintenance cost	Inspection, servicing, spare parts, and labour
Gas handling cost	SF6 recovery, refilling, monitoring, and certified personnel
Downtime risk	Cost of planned and unplanned outages
Compliance cost	Reporting, documentation, and future regulatory exposure
End-of-life cost	Decommissioning, gas recovery, and disposal

If existing SF6 switchgear is leaking, obsolete, or expensive to maintain, SF6-free replacement may offer better lifecycle value even if the upfront cost is higher.

When You May Not Need Immediate Replacement

Not every SF6 switchgear asset needs to be replaced immediately.

If the equipment is relatively new, leak-free, compliant, well maintained, and critical to current operations, immediate replacement may not be commercially necessary. In this case, the best approach may be to create a phased replacement strategy.

A phased plan can include:

• Auditing existing SF6 assets

• Recording gas quantity and leakage history

• Ranking switchgear by age and risk

• Identifying assets due for upgrade

• Planning replacement during scheduled shutdowns

• Specifying SF6-free switchgear for all new installations

• Preparing end-of-life gas recovery procedures

This approach allows asset owners to reduce risk without creating unnecessary disruption.

Key Questions Before Replacing SF6 Switchgear

Before deciding to replace SF6 switchgear with SF6-free switchgear, ask these questions:

1. How old is the existing switchgear?

2. Has it experienced gas leakage or pressure alarms?

3. Are spare parts still available?

4. Is maintenance becoming more expensive or difficult?

5. Is the site planning an upgrade or expansion?

6. Are sustainability or ESG targets influencing procurement?

7. Could future regulations affect the asset during its service life?

8. Is downtime risk increasing?

9. Does the project require a safer and simpler maintenance profile?

10. Would SF6-free technology reduce long-term operational complexity?

If several answers point to risk, replacement should be evaluated seriously.

SF6-Free Switchgear as a Future-Ready Alternative

Modern SF6-free switchgear is no longer experimental. Many solutions use established vacuum interruption technology combined with clean air, dry air, or other low-impact insulation methods.

Leistung Energie’s SF6-free Airing solution is listed as a 12 kV, 1250 A, 25 kA medium voltage switchgear option using dry air with no SF6 and no greenhouse gas. Its listed features include an IP68 stainless steel gas tank, internal arc fault type testing, integrated interlocking, and more than 90% recyclable materials.

For project owners, this means SF6-free switchgear can be considered not only for environmental reasons, but also for safety, reliability, lifecycle planning, and future procurement strategy.

---

You should replace SF6 switchgear with SF6-free switchgear when the existing asset is ageing, leaking, difficult to maintain, costly to service, or already part of a planned electrical upgrade.

You should also consider replacement when corporate sustainability targets, regulatory exposure, or long-term procurement risk make SF6-based equipment less attractive.

However, replacement does not always need to be immediate.

For reliable and compliant SF6 assets, a phased strategy may be the most practical approach. The key is to stop treating SF6 switchgear as a “fit-and-forget” asset and start managing it as part of a long-term transition plan.

For new installations, major upgrades, renewable energy projects, data centres, commercial buildings, utilities, and critical infrastructure, SF6-free switchgear is increasingly the more future-ready choice. It reduces environmental risk, simplifies gas management, and supports a cleaner, safer, and more sustainable electrical network.

To evaluate the right replacement strategy for your site, contact Leistung Energie to discuss SF6-free switchgear options, project requirements, technical specifications, and long-term lifecycle planning.
